Memory Craft 500E Limited Edition Embroidery Machine
Now designers can create projects that reflect their personal sense of style with the Memory Craft 500E Limited Edition. Easily personalize, embellish, and monogram home décor items, garments, and accessories. With 160 built-in embroidery designs and 6 fonts for monogramming, the possibilities are endless.
The MC500E Limited Edition offers a maximum embroidery size of 7.9” x 11” and comes with 4 embroidery hoops:
- RE28b 7.9″ x 11″
- SQ20b 7.9″ x 7.9″
- RE20b 5.5″ x 7.9″
- SQ14b 5.5″ x 5.5″
It also includes an extra-wide table for expansive workroom projects.
Features
- Designs easily imported through the direct port
- Advanced on-screen editing functions via the new LCD color touchscreen
- On-screen editing includes: enlarge/reduce, rotate, flip, drag and drop, arc, combine, copy and paste, grouping, corner layout, single color sewing, zoom
- Embroidery sewing speed: 400–860 SPM
- Flexible stitch traveling (by units of 1, 10, 100)
- Auto return post thread break
- Adjustable hoop positioning
- Thread cutter included
Included Accessories
- AcuStitch (PC-Compatible Software)
- USB drive with 30 large exclusive designs
- Bobbin (Standard) & Bobbin Holder for Embroidery (High Tension)
- Extra Wide Table 500E/400E
- Large Screwdriver & Triangle Screwdriver
- Lint Brush
- Special Spool Holder
- Touch Panel Stylus
Technical Specifications
- Number of Designs: 160
- Fonts for Monogramming: 6 (2 and 3-letter monograms)
- Maximum Embroidery Size: 7.9" x 11"
- Design Transfer Options: USB
- Embroidery Format: .JEF
- Programmable Jump Thread Trimming: Yes
- Adjustable Speed While Embroidering: Yes
- Screen Type: LCD Full Color Touchscreen
- Thread Brand Selection: Janome, Robison-Anton, Madeira, Mettler
- Hook Type: Top Loading Full Rotary Hook Bobbin
- Thread Tension Control: Automatic
- Needle Threader: Superior
- Feed System: 7-Piece Feed Dog
- Start/Stop Button: Yes
- Automatic Thread Cutter: Yes
- Machine Size Footprint: W 23" x H 12.9" x D 17.7"
- Machine Weight: 11.5 lbs
- Workspace: W 12" x H 4.7"
- Bobbin Winding: Bobbin Winder with Plate and Cutting Blade
- Extra High Presser Foot Lift: Yes
- Dual Voltage 80v - 240v: Yes
- Cover: Dust Cover
Available Hoops
- RE28b Hoop (200 x 280 mm / 7.9" x 11")
- SQ20b Hoop (200 x 200 mm / 7.9" x 7.9")
- RE20b Hoop (140 x 200 mm / 5.5" x 7.9")
- SQ14b Hoop (140 x 140 mm / 5.5" x 5.5")
- RE10b Hoop (optional) (40 x 100 mm / 1.5" x 5.5")
